PINNACLE® Introducer Sheaths

PRODUCT OVERVIEW

Femoral Access Sheath for Coronary or Peripheral Procedures available in 4-11F, 10 or 25cm lengths

  • Smooth transition of guidewire to dilator and dilator-to-sheath
  • Kink resistant design
  • Small OD and large ID minimizes the size of the access site without compromising ease of device passage
  • Snap-on dilator lock prevents backout during insertion

PRODUCT CODES

PINNACLE Introducer Sheaths - Coronary Applications

Product Code Length Inner Diameter Dilator Protuding Length Mini Guidewire Diameter Mini Guidewire Length
RSS402 10 4 2.5 .035* 45
RSS502 10 5 2.5 .038* 45
RSS602 10 6 2.5 .038* 45
RSS702 10 7 2.5 .038* 45
RSS802 10 8 2.5 .038* 45
RSS902 10 9 2.5 .038* 45
RSS002 10 10 2.5 .038* 45
RSS102 10 11 2.5 .038* 45
RSS404 10 4 2.5
RSS504 10 5 2.5
RSS604 10 6 2.5
RSS704 10 7 2.5
RSS804 10 8 2.5
RSS904 10 9 2.5
RSS004 10 10 2.5
RSS104 10 11 2.5
RSS506 25 5 2.5
RSS606 25 6 2.5
RSS706 25 7 2.5
RSS806 25 8 2.5
RSS906 25 9 2.5
RSS006 25 10 2.5
RSS106 25 11 2.5
*Mini stainless steel spring coil guidewire included. Maximum guidewire compatible size: 0.035" for 4 Fr, 0.038" for all others

PINNACLE Introducer Sheaths - Peripheral Applications

Product Code Length Inner Diameter Dilator Protuding Length Mini Guidewire Diameter Mini Guidewire Length
RSS401 10 4 2.5 .035* 45
RSS501 10 5 2.5 .035* 45
RSS601 10 6 2.5 .035* 45
RSS701 10 7 2.5 .035* 45
RSS801 10 8 2.5 .035* 45
RSS901 10 9 2.5 .035* 45
RSS001 10 10 2.5 .035* 45
RSS101 10 11 2.5 .035* 45
RSS403 10 4 2.5
RSS503 10 5 2.5
RSS603 10 6 2.5
RSS703 10 7 2.5
RSS803 10 8 2.5
RSS903 10 9 2.5
RSS003 10 10 2.5
RSS103 10 11 2.5
RSS505 25 5 2.5
RSS605 25 6 2.5
RSS705 25 7 2.5
RSS805 25 8 2.5
RSS905 25 9 2.5
RSS005 25 10 2.5
RSS105 25 11 2.5
*Mini stainless steel spring coil guidewire included. Maximum guidewire compatible size: 0.035" for 4 Fr, 0.038" for all others

DOCUMENTS

Pinnacle Dimension Sheet
Pinnacle Dimension Sheet
Pinnacle Family Brochure
Pinnacle Family Brochure
TMC Latex Letter
TMC Latex Letter
TMC Materials of Concern Letter
TMC Materials of Concern Letter

REFERENCES

RX ONLY. Refer to the product labels and package insert for complete warnings, precautions, potential complications, and instructions for use.
